MEI Talos T602-U5EUS Amusement Bill Acceptor
- SKU
- T602-U5EUS
More Information
| Manufacturer | MEI |
|---|---|
| Voltage | 24v/34v DC |
| Bezel type | VFM (Up stacker) "0" |
| Cashbox Size | 500 Stacker |
| Currency Accepted | United States Dollar |
| Denominations | $1-$20 |
| Bill Recycler | No |
| Bezel Specs |  |
| Cashbox Specs |
|
Description / MEI Talos T602-U5EUS Amusement Bill Acceptor
Overview
The MEI Talos T602-U5EUS is a U.S.-currency MDB bill validator engineered for vending, kiosk, and amusement applications. As part of the Talos T6 Series, it replaces the discontinued AE2602-U5EUS and delivers faster bill acceptance, stronger anti-fraud protection, and easier field maintenance.
Built with MEI’s proven Talos technology, the T602-U5EUS combines high-precision optical sensors, gear-driven transport, and modular construction for long service life. It supports $1–$20 note acceptance, features tool-free stacker removal, and provides full MDB interface compatibility for plug-and-play upgrades.
Key Features
- Accepts U.S. $1–$20 bills with advanced optical sensing
- MDB interface for vending and amusement systems
- Replaces legacy AE2602-U5EUS
- Enhanced anti-stringing and counterfeit detection
- Standard Talos bezel for secure front-entry installation
- Field-upgradeable firmware via USB or handheld device
- Quick-release stacker and modular design for fast service
- Durable gear-driven mechanism for reliable long-term operation
Technical Specifications
| Currency | U.S. Dollar (USD) |
|---|---|
| Interface | MDB Protocol |
| Bezel Type | Standard Talos Entry Bezel |
| Operating Voltage | 24 V DC |
| Stacker Capacity | Up to 500 notes (up-stacker configuration) |
| Bill Insertion | 4-way acceptance (any orientation) |
| Firmware Update | USB or handheld programmer |
| Operating Temperature | 0 °C – 50 °C (32 °F – 122 °F) |
Model Breakdown
| Code | Meaning | Description |
|---|---|---|
| T | Talos Series | MEI’s next-generation validator platform offering improved durability and performance. |
| 6 | Model Family | T6 Series — replaces the older AE26xx validator family. |
| 0 | Form Factor | Standard Talos model for vending and kiosk installations. |
| 2 | Interface Type | MDB protocol for vending and amusement machines. |
| U5 | Stacker Configuration | Up-stacker with 500-note stacker box for compact vending and amusement applications. |
| EUS | Build Code | U.S. standard MDB build (E-series mainboard) with extended compatibility and Talos firmware. |
Summary:
The MEI Talos T602-U5EUS replaces the AE2602-U5EUS, offering faster note recognition, enhanced durability, and plug-and-play MDB integration for vending and amusement systems.
