ICT WEL-R7U02 Cable
The ICT WEL-R7U02 Cable is a ICT wiring part for connecting a bill acceptor, printer or converter board to the machine that controls it. Getting the harness right matters: the wrong pinout can leave a validator powered but silent, or stop it from sending credits. Match the connector, voltage and…
| SKU | WEL-R7U02 |
|---|
Secure checkout on billacceptors.us, our official online store. Questions? 877-922-6707
Description / ICT WEL-R7U02 Cable
The ICT WEL-R7U02 Cable is a ICT wiring part for connecting a bill acceptor, printer or converter board to the machine that controls it.
What it does
Getting the harness right matters: the wrong pinout can leave a validator powered but silent, or stop it from sending credits. Match the connector, voltage and interface below to your machine before you install it. It speaks ccTalk as well as simpler signalling, so it fits many control boards.
Specifications
| Part no. | WEL-R7U02 |
|---|---|
| Cable | 2464 22AWG 4C CABLE |
| Connector | D-SUB(F) |
| Protocols | Pulse, RS232, ccNet, RS232 A0, ccTalk |
| Voltage | 12V DC |
Wire-by-wire: On the D-SUB 9F top view,
| Signal | Pin | Wire colour |
|---|---|---|
| TXD | 2 | is |
| RXD | 3 | is |
| GND | 5 | is |
Wire-by-wire: The TMT 24 back-view wiring assigns
| Signal | Pin | Wire colour |
|---|---|---|
| to Ground | 1 | blue |
| to TX1 | 2 | purple |
| to RX1 | 3 | black |
| to Download VCC | 6 | white |
Good to know
- The cable is listed for ICT L70, L70F, L70T, L77F, L77T, and L83 bill acceptor platforms.
- The 2-BA-RNK10 interface uses 12V DC for RS232 or ICT Protocol data communication.
Help from E&D Trading
Not sure this is the right cable? Call 877-922-6707. E&D Trading has more than 30 years of experience and can check fitment against your machine before it ships.
