Goldfinger 19-Inch GF19S13A1 Non-Standard

Part Number: 401107

Technical Specifications:

Touch Technology & Capacity:

• Touch Type: PCAP (Projected Capacitive) – Multi-Touch
• Touch Interfaces: USB and Serial

Display:

• Diagonal Size: 19” Active Matrix TFT LCD
• Aspect Ratio: 16:9
• Active Area: 374.78 mm (H) x 299.83 mm (V)
• Max Resolution: 1280 (H) x 1024 (V)
• Pixel Pitch: .097 (H) x .097 (V)
• Supported Resolutions: 640 x 480, 800 x 600, 1024 x 768, 1280 x 720, 1280 x 800, 1280 x 960, 1280 x 1024, 1360 x 768, 1366 x 768, 1440 x 900, 1680 x 1050, 1920x1080
• Video Refresh Rate: 54Hz – 67.5Hz
• Video I/O Ports: HDMI, DVI-D, VGA
• Viewing Angle: Horizontal ±89°, Vertical ±89°
• Brightness: 250 nits
• Number of Colors: 16.7M
• Contrast Ratio: Typ: 1000:1, Min: 700:1
• Response Time: Typ: 14ms, Max: 20ms

Power:

• Power Supply: 24V DC Adapter
• Input Voltage Range: 100-240V
• Power Consumption: Typ: 13 W, Max: 17.4 W

Dimensions & Weight:

• Monitor Dimensions: 417 mm x 343 mm x 54 mm
• Weight: 10.2 lbs (4.63 kg)

Environmental:

• Operating Temperature: 0°C to +50°C
• Storage Temperature: -20°C to +60°C
• Humidity Range: 10% - 80% Relative Humidity

On Screen Display:

• Accessible with Remote: Controls include Power, Back, Left, Right, Menu, Overscan
• Settings: Picture Mode, Contrast, Brightness, Color, Tint, Sharpness, Backlight, Color Temp, Aspect Ratio, Noise Reduction, Mirror, Clock, Off Time, On Time, Sleep Timer
• Languages: English, French, Italian, German, Spanish, Chinese, Japanese

Mounting Options:

• VESA: 100mm x 100mm, 200mm x 200mm
• Pre-Defined Perimeter Mounting: Yes

Warranty & Approvals:

• Warranty: 3 Years Standard
• Regulatory Approvals: UL, FCC

Touchscreen:

• Glass Treatment: Chemically treated for strength
