American Changer AC6005 Rear Load Banknote Changer
Need a changer that handles heavy traffic while all servicing happens from a secure room behind the wall? The American Changer AC6005 is a rear-load, high-capacity bill changer. It has two banknote validators and four coin hoppers, so it keeps paying out during your busiest hours. Rear-load design:…
| SKU | AC6005 |
|---|
Secure checkout on billacceptors.us, our official online store. Questions? 877-922-6707
Description / American Changer AC6005 Rear Load Banknote Changer
Need a changer that handles heavy traffic while all servicing happens from a secure room behind the wall? The American Changer AC6005 is a rear-load, high-capacity bill changer. It has two banknote validators and four coin hoppers, so it keeps paying out during your busiest hours.
Why operators choose the AC6005
- Rear-load design: your staff fills and services it from behind the wall
- Two banknote validators; the base unit ships with Pyramid validators
- Takes $1, $5, $10 and $20 bills
- 1,400 notes of total storage in two 700-note stackers*
- 22,400 coins total in four hoppers, each holding 5,600 quarters**
- Pays out about 4 coins per second on average
- Up to 4 different coin values (with an additional hopper)
- Flex-2 control board; switchable 115/230 V, 50/60 Hz input
- Choice of Change or Token decal, with custom designs available
Specifications
| Model | AC6005 High Capacity Bill Changer – Rear Load |
|---|---|
| Bill validators & stackers | 2 validators; two 700-note stackers (1,400 bills total)* |
| Bills accepted | $1, $5, $10, $20 |
| Coin hoppers | 4; 5,600 quarters each (22,400 total)**; ~4 coins/sec |
| Electrical | Switchable 115/230 V, 50/60 Hz; various plug configurations |
| Power consumption | Board 15 W max; hopper 22 W max; validator 50 W max |
| Control board | Flex-2 |
| Ambient temperature | 41°–122°F (5°–50°C) |
| Cabinet dimensions*** | 24.6 W × 30 H × 18.3 D in (62.42 × 76.15 × 46.45 cm) |
| Weight*** | 250 lb (about 113.4 kg) |
| Faceplate dimensions*** | 27.6 W × 33 H in (70.04 × 83.81 cm); 25 lb (11.34 kg) |
| Warranty | Generally a limited 1-year warranty on parts and labor (performed at the factory) and a limited 2-year warranty on banknote validators |
Options you can add
- NAYAX System Upgrade (AC7777-NAYAX): Ethernet or cellular credit card system for tokens (MDB only)
- Heater (AC1061-HTR): internal electric strip heater that protects against freezing
- High Security Lock & Key (AC1095-D2): hardened steel with special keys
- T-Handle (AC5080-QSPINS): drill resistant
- Micro-Coin Acceptor (AC2067-Kit): lets the machine accept quarters or other coins
- Remote Access Kit (AC6075): remote monitoring and auditing (cash in, credit card transactions, total sales), failure alerts and remote payouts
- CPI Validator w/ 500 Stacker (AC9003.7-500)* or w/ 700 Stacker (AC9003.7-700)*
- Custom Decal*: a decal designed with your own artwork or logo
Ordering from E&D Trading
E&D Trading has more than 30 years of experience with coin and currency equipment. A cabinet this size ships by freight, so ask us for a delivery quote. Call 877-922-6707 and we will help you pick the right options for your location.
*Stacker capacity is based on a USA banknote. American Changer determines the validator brand. **Hopper capacity is based on a USA quarter or USA $1 coin and changes with coin size. ***Dimensions and weights are estimates measured before packaging or shipment. Specifications from American Changer (Mar 2026).
